Fisher & Paykel 13cm Series 11 Auxiliary Downdraft Extractor

Original price $2,999.00 - Original price $2,999.00
Original price $2,999.00
$2,999.00
$2,999.00 - $2,999.00
Current price $2,999.00

or payment options selectable at checkout:

laybuy-logo-icon $1,799.00 + 5x $240

Found a lower price? Give us a call

available-green-tick-icon AVAILABLE
North Island delivery or pick-up FREE at Auckland or Kaitaia locations
(Usually takes 3-10 working days)

  • With powerful extraction, this ventilation module fits seamlessly into your benchtop. Combine with our Primary Induction Cooktop and other modular cooktops for the ultimate culinary solution.
    • Part of our distinctive modular cooking system. Combine with a primary cooktop for a cohesive cooking experience.
    • Seamless integration into the kitchen, eliminating the need for overhead ventilation.
    • Connects to neighboring cooktop modules, with automatic extraction at the appropriate speed for your cooking.
    • Features five fan speeds and a boost function for efficient removal of odors and steam.

    Modular Design Flexibility

    Enhance your cooking area with downdraft ventilation. These modules can be discreetly arranged next to your primary cooktop and additional modules, ensuring a fresh atmosphere no matter your cooking method. Customize your setup to reflect your lifestyle, cooking habits, and entertaining style.

    Sleek And Subtle

    Transform your kitchen's look with the downdraft ventilation module. Seamlessly integrated into the countertop and alongside cooktop modules, it facilitates an open-style, social kitchen. Choose from stylish black glass or understated grey glass finishes that match your kitchen's design.

    Design Versatility

    Perfect for layouts where conventional overhead hoods are impractical, this ventilation module pairs beautifully with island cooktops and open kitchens. Its ability to retract or conceal ensures a tidier, more spacious appearance, enhancing both functionality and design in your kitchen.

    Intuitive Extraction

    Simply lift the cover for convenient extraction with Link Mode. The fan automatically activates, adjusting its speed based on the power levels of adjacent cooktop zones, removing the need for manual settings. Even after cooking is complete, the fan remains on to capture any lingering vapors.

    Quiet Efficiency

    The auxiliary ventilation module operates effectively and quietly in the background, seamlessly managed through the primary module touchscreen. With five fan speeds plus a boost function, it swiftly eliminates steam, odors, and grease.

    Prolonged Freshness

    A Delayed Off timer guarantees that cooking odors are extracted even after you finish cooking. Furthermore, the timer will automatically turn off the ventilation after a set duration, minimizing energy waste if you forget to switch it off.

    Easy To Clean

    The nine-layer filter efficiently captures grease particles during extraction. Designed for easy removal, the filters are simple to clean and dishwasher safe.

  • Height 186mm
    Width 130mm
    Depth 530mm
    Fan ratings
    Maximum air movement 573m³/hr
    Maximum sound rating 75dba
    Speed 1 sound rating 42dba
    Installation and cleaning
    Dishwasher safe filters 1
    Recirculation Optional
    Stainless steel filter cover
    Performance
    Extraction type Surface
    Fan speeds 5 + Boost
    Filter type Mesh with Stainless Steel filter cover
    Number of filters 1
    Power requirements
    Supply frequency 50Hz
    Supply voltage 220-240v
    Total Power 167w
    Product dimensions
    Depth 530mm
    Height 186mm
    Width 130mm
    Ventilation features
    Auto-off/Run-on timer
    Smart Appliance
